DIP Switches Hold the Code

DIP Switches are also known as:

Dual-in-line package

Slide switch package

Single pole single throw (SPST) switch

Upright DIP

DIP switch applications include:

Remote control

Audio adjuster

Machine coder

Embedded logic

Deep Dive on Upright DIP Switches

DIP switches come in horizontal or upright orientation. The redesigned upright DIP provides an alternative to the piano-type, commonly used in panel mount applications.

The upright switch package is mounted on the PCB in such a way that it can be placed directly up against a panel. This allows the operator or the end-user to adjust the movable actuator, unlike traditional DIP switches which are encased in the enclosure. This is especially useful in audio applications where different channels need to be user manipulated. There are also an increasing number of industrial applications where it is necessary to mechanically change signal circuits.

Some highlights of Upright DIP Switches include:

Reinforced soldering leads

Improved contact design for optimal strength

Extended pin insulator allowing more flexibility for the designer

Single pin construction for decreased resistance
